In stock 1 available
Compact modular air pressure regulator used in pneumatic systems to maintain consistent downstream pressure within adjustable limits, suitable for general industrial and automation applications. Model: AR2500 Type: Pneumatic Air Regulator Thread Size: 1/4" NPT (standard); also available in Rc1/4 or G1/4 variants Port Size: 1/4" Pressure Adjustment Range: 0.05 to 0.85 MPa (7 to 120 PSI) Max Supply Pressure: 1.0 MPa (145 PSI) Gauge Port: 1/8" (on both sides; optional pressure gauge can be mounted) Construction: Die-cast aluminum body, polycarbonate bowl cover (when applicable) Regulating Mechanism: Diaphragm-operated, relieving type Mounting: Panel mount or bracket mount (optional L-bracket available) Weight: ~0.25 kg Temperature Range: -5 °C to 60 °C (23 °F to 140 °F) Flow Rate: ~600 L/min (depending on pressure and downstream load) Features: • Lockable adjusting knob • Modular connection with other SMC FRL units (filters/lubricators) • Optional bracket and pressure gauge • Compact size for tight panel applications Application: Air line regulation for cylinders, valves, tools, and pneumatic circuits requiring stable pressure
Condition: Used
Weight: 1.04
Depth: 4.00
Length: 10.00
Width: 8.00
SKU: 4366 4.S6.1.3
