Allen-Bradley MPL-B330P-RK22AA SER.A AC Rotary Servo Motor, 1.8kW 100mm Frame

The Allen-Bradley MPL-B330P-RK22AA is a compact 100 mm frame AC rotary servo motor from the MPL series, offering 1.8 kW of continuous power. Designed for high-performance motion control in industrial applications, it integrates seamlessly with Kinetix servo drives. Technical Information: Model: MPL-B330P-RK22AA Series: MPL (Kinetix Rotary Servo Motors) Motor Type: AC Rotary Servo Motor Power: 1.8 kW (2.4 HP) Voltage: 460V-class (nominal 325V DC bus) Continuous Stall Torque: ~4.18 Nm Peak Torque: ~19.1 Nm Base Speed: 3000 RPM Max Speed: 5000 RPM Continuous Current: ~3.6 A (RMS) Peak Current: ~10.8 A (RMS) Frame Size: 100 mm (Frame B) Mounting: IEC metric flange Shaft Type: Keyless shaft Feedback: Resolver (RK22AA variant) Brake: No brake Cooling Method: Natural convection Insulation Class: F Enclosure: IP65 with shaft seal Connector Orientation: Side-exit bayonet connectors Ambient Temperature: 0°C to 40°C Duty Cycle: Continuous (S1)

Condition: New

Weight:   15.00

Depth:   10.00

Length:   17.00

Width:   6.00

SKU:   43836 4.S5.11.1
