In stock 2 available
Stackable hydraulic modular valve used for flow control and directional flow bypass in high-pressure systems, built to standard NG6/CETOP 3 interface specifications. Model: OY-G01-T-20 Brand: Nachi Type: Modular Bypass Valve Function: Bypass type flow control or unloading valve Mounting Interface: G01 (NG6 / CETOP 3 / ISO 4401-03 pattern) Pressure Rating: Up to 25 MPa (250 bar / 3625 PSI) Flow Rating: Up to 40 L/min Control Port: Pilot-controlled via subplate channeling Mounting Style: Sandwich (modular) with subplate/manifold stack Material: High-strength steel block with corrosion-resistant finish Orientation: Universal mounting Seal Material: NBR (standard) or optional FKM for high-temp fluids Application: Enables controlled diversion or bypass of hydraulic flow in manifold blocks—commonly used in energy-saving circuits, unloading pump flow, or secondary pressure control branches Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 1.14
Depth: 4.00
Length: 7.00
Width: 7.00
SKU: 4399 4.S4.16.4
