In stock 1 available
Compact and reliable switching power supply designed for industrial control panels, delivering stable 24 VDC output with integrated status monitoring. Model: S8VS-09024 Type: Switching Power Supply Input Voltage Range: 100–240 VAC, 50/60 Hz Input Current: 2.3 A max Inrush Current: ≤ 35 A (at 230 VAC) Output Voltage: 24 VDC Output Current: 3.75 A Output Power: 90 W Voltage Adjustment Range: 22–28 VDC (via front potentiometer) Efficiency: Approx. 85% Status Indicators: • DC OK indicator • Alarm output (relay contact) for undervoltage or failure Protection Features: • Overvoltage protection • Overload/overcurrent protection • Short circuit protection • Overtemperature shutdown Mounting: DIN rail (35 mm standard) Cooling: Natural air convection Operating Temperature: –10 °C to +60 °C (derating above 45 °C) Certifications: UL, cUL, CE, TUV, RoHS compliant Case Material: Flame-retardant resin Dimensions: 97 mm H × 35 mm W × 95 mm D Weight: ~350 g Application: Used in factory automation, machine control, PLC systems, and instrumentation requiring reliable 24 VDC regulated power Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 0.15
Depth: 4.00
Length: 10.00
Width: 8.00
SKU: 4404 4.S9.14.3
