In stock 9 available
High-performance dual-channel switching amplifier for intrinsic-safe Namur sensor applications, featuring programmable outputs and ATEX approval for hazardous environments. Model: N0032A Type: 2-channel switching amplifier for Namur sensors Input Voltage: 115 VAC (45–65 Hz), ±10% Power Consumption: 1.3 VA Outputs: 2 relay outputs (1 changeover contact per channel) Contact Rating: 253 VAC / 2 A (cos φ > 0.7) or 40 VDC / 2 A resistive Switching Frequency: 10 Hz Detection Range: Sensor current switching points at 1.2–2.1 mA Monitoring: Programmable functions with short-circuit and wire-break detection Certifications: ATEX II (1) G D [Ex ia], TIIS, IECEx (hazardous-area safe) Ambient Temp: –20 °C to +60 °C Protection Rating: IP20 Indicators: Green LED: Power on Yellow LEDs (x2): Output channel status Red LEDs (x2): Function/programming indicators Mounting: DIN rail (spring clip) Electrical Connection: Screw terminals for up to 2.5 mm² conductors Mechanical Life: 10 million cycles Weight: ~210 g Dimensions: ~118 × 20 × 110 mm Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 1.50
Depth: 4.00
Length: 10.00
Width: 8.00
SKU: 4411 4.S8.4.4
