Mitsubishi Electric FREQROL-E700,FR-E720-0.4K 3-Phase Inverter, 0.5 Motor HP

The Mitsubishi Electric FREQROL-E700 FR-E720-0.4K is a compact 3-phase inverter designed for variable speed control of AC motors. It offers high-performance motor control in a user-friendly format, ideal for compact machinery and general-purpose industrial applications. Technical Specifications Series: FREQROL-E700 Model: FR-E720-0.4K Motor Capacity: 0.4 kW (approx. 0.5 HP) Input Voltage: 3-phase 380–480V AC ±10% Input Frequency: 50/60 Hz ±5% Output Voltage: 3-phase 0–480V AC (depends on input) Output Frequency: 0.2–400 Hz Rated Output Current: 1.5 A Overload Capacity: 150% of rated current for 60 seconds Control Method: V/f control, Sensorless vector control Braking: Built-in brake transistor (up to 1.5kW) Protection Features: Overcurrent, overvoltage, undervoltage, overload, ground fault, stall prevention Ambient Temperature: -10°C to +50°C (derating above 40°C) Enclosure Rating: IP20 (open type) Cooling Method: Self-cooling or fan (model dependent) Dimensions: Approx. 150 mm H × 100 mm W × 80 mm D Weight: Approx. 1 kg Interface: Digital operator (LED display), optional analog/digital inputs, RS-485 Modbus RTU communication Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   1.09

Depth:   6.00

Length:   12.00

Width:   9.00

SKU:   4436 4.S8.4.1
