In stock 2 available
Robust, single‑pole power distribution block with aluminum connector in a compact, finger‑safe enclosure—ideal for distributing a 115 A feed to up to four loads. Technical Specifications Model: 1492‑PDME1141 Manufacturer: Allen‑Bradley (Rockwell Automation) Configuration: 1‑pole Line-side openings: 1 Load-side openings: 4 Rated Current: 115 A per pole Rated Voltage: 600 V AC/DC (UL); 1000 V AC/DC (IEC) Connector Material: Aluminum (enclosed type) Wire Range (Cu): #2–14 AWG (line); #10–14 AWG (load) Mounting: DIN-rail or panel mount (integrated feet) Housing: Thermoplastic enclosure, IP20 finger-safe front SCCR (Short‑Circuit Current Rating): 100 kA (when protected per spec) Torque Specs: Line/load screws: ~35 lb‑in (4 N·m) hex head Wire Strip Length: Approx. 0.31 in (8 mm) Operating Temp: –40 °C to +90 °C Certifications: UL Listed, UL Recognized, CSA, CE, RoHS compliant Dimensions (approx): Length 112 mm, width ~45 mm, height ~56 mm Weight: ~0.35 kg Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 0.10
Depth: 4.00
Length: 7.00
Width: 7.00
SKU: 4561 4.S10.1.3C
