In stock 1 available
Technical Specifications: Power Supply: Universal AC voltage range of 90 to 130V or 180 to 250V, accommodating various power system requirements. Output Signals: Analog Output: 4 to 20 mA DC, proportional to flow rate. Digital Output: DE protocol for direct digital communication with compatible systems. Pulse Output: Configurable frequency range from 0.00006 to 3000 Hz, with adjustable pulse width between 0.10 to 999.99 ms or fixed at 50% duty cycle. Contact Inputs/Outputs: Inputs: Up to two solid-state or no-voltage contacts for functions such as external zero adjustment or range switching. Outputs: Up to two open collector outputs for alarms, range status, or counter presets, with a capacity of DC 30V max, 200 mA max. Environmental Conditions: Ambient Temperature: Operational range from -25°C to 60°C (-13°F to 140°F). Humidity: Suitable for environments with 5 to 100% relative humidity.
Condition: New
Weight: 25.00
Depth: 16.00
Length: 16.00
Width: 16.00
SKU: 46430 4.R6.4.1
