Siemens 1LG6183-2AA60 AC Motor, 24.5KW

The Siemens 1LG6183-2AA60 is a three-phase asynchronous low-voltage motor from the SIMOTICS SD series, designed for industrial applications requiring reliable performance. This motor is optimized for IE1 efficiency and features a robust gray cast iron housing. Key Technical Specifications: Power Output: 22 kW at 50 Hz 24.5 kW at 60 Hz Voltage and Frequency: 400 VΔ / 690 VY at 50 Hz 460 VΔ at 60 Hz Speed: 2-pole design Approximately 3000 RPM at 50 Hz Approximately 3600 RPM at 60 Hz Frame Size: 180M Protection and Insulation: IP55 degree of protection Temperature class 155 (F) Mounting Configurations: IM B3 (foot-mounted) IM B6, IM B7, IM B8 (various wall-mounted positions) IM V5 (vertical shaft down without canopy) IM V6 (vertical shaft up)

Condition: Used

Weight:   295.00

Depth:   27.00

Length:   35.00

Width:   21.00

SKU:   47041 4.R1.2.7
