In stock 3 available
This is a thermal overload relay designed to provide motor protection by detecting excess current conditions. It mounts directly to Siemens contactors and provides automatic or manual reset functionality. Model: 3UA50 00-1C* Rated Operational Voltage: 600 VAC Current Adjustment Range: 1.6 – 2.5 A Tripping Class: Class 10 Tripping Current: 125% of dial setting Reset Type: Manual/Automatic selectable Auxiliary Contacts: 1 Normally Open (97–98), 1 Normally Closed (95–96) Mounting: Contactor-mountable (typically on Siemens 3TF or 3RT series) Operating Frequency: 50/60 Hz Test Button: Yes (red push button) Ambient Temperature Compensation: Yes Terminal Torque: 1.3 lb-in Protection: Phase failure sensitive, overload protection Approvals: UL Listed, CSA, IEC, VDE Housing: Open-style, panel/conductor mount Country of Origin: Germany Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 0.20
Depth: 4.00
Length: 7.00
Width: 7.00
SKU: 5180 4.S4.16.4
