In stock 2 available
This is a compact motor circuit breaker from Telemecanique, used for protecting motors against overload, short-circuit, and phase failure. It integrates start/stop control and adjustable current settings. Model: GV1-M07 Manufacturer: Telemecanique (Schneider Electric) Function: Manual motor starter / protector Rated Operating Voltage: 660 V AC Rated Current Range: 1.6 – 2.5 A (adjustable dial) Trip Class: Class 10 Tripping Threshold: 125% of dial setting Interrupting Capacity (Icu): – 100 kA @ 380/415 V – 50 kA @ 440 V – 25 kA @ 500 V – 10 kA @ 660 V Horsepower Ratings (3-phase): – 0.5 HP @ 115 V – 1 HP @ 230 V – 2 HP @ 460 V – 3 HP @ 575 V Controls: – Red STOP/RESET button – Grey START button – Test button Standards: IEC 60947, UL 508, CSA C22.2 Mounting: DIN rail Terminals: Screw type Torque Rating: 20 lb-in Ambient Temperature Rating: Compensated Country of Origin: France Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 0.50
Depth: 4.00
Length: 7.00
Width: 7.00
SKU: 5182 4.S1.0.1
