In stock 1 available
Industrial control relay with 2 normally open and 2 normally closed contacts, designed for switching auxiliary circuits. Equipped with a 24VDC coil and capable of general-purpose switching at up to 240V AC, 10A. Model: 3TH2022-0BB4 Contact Configuration: 2NO + 2NC Coil Voltage: 24 VDC Rated Operational Voltage: 240 VAC max Rated Current: 10 A AC-15 Rating (230V): 3 A AC-15 Rating (400V): 1.9 A DC-13 Rating (24V): 1.7 A Wire Capacity: 2×(0.5–2.5 mm²) or 1×(4 mm²) Terminal Torque: 0.8–1.3 Nm Auxiliary Contact Ratings: A600/Q300 Standards: IEC 947, VDE 0660, UL, CSA Mounting: DIN rail Made in: Germany Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 1.00
Depth: 4.00
Length: 7.00
Width: 7.00
SKU: 5193 4.S9.10.2
