Exlar GSX20-0602-MFM-AB1-268 Servo Motor Linear Actuator

This unit is an integrated servo linear actuator from Exlar’s GSX Series, combining a brushless servo motor and a roller screw actuator into one compact housing. It offers high force, precision motion, and long life, ideal for industrial automation and motion control applications. Technical Specifications Model: GSX20-0602-MFM-AB1-268 Part Number: 200234 Serial Number: 3310661A Voltage: 460 V AC Current: 1.2 A Rated Speed: 5,000 RPM Lead/Ratio: 0.2 in/rev (roller screw lead) Frame Size: GSX20 (corresponds to approx. 2 in stroke dia, mid-sized force range) Stroke Length: 6.02 inches Mounting Style: AB1 (likely front flange with anti-rotation or trunnion, depending on Exlar’s code) Feedback Device: MFM (Magnetic absolute encoder – likely SSI or analog output) Environmental Protection: Typically IP54/IP65 (depends on sealing and connectors) Lubrication: Grease-lubricated planetary roller screw, serviceable Force Capability: Approx. 1,000–2,500 lbf (depending on speed, duty cycle, and lead)

Condition: Used

Weight:   19.00

Depth:   8.00

Length:   8.00

Width:   16.00

SKU:   52251 4.S5.5.3
