In stock 5 available
Description: Compact pneumatic cylinder with high-performance features for industrial automation Bore Size: 50 mm Stroke Length: 320 mm Actuation: Double-acting Mounting Style: Universal with rear and front mounting options Cushioning: Adjustable pneumatic cushioning at both ends Operating Pressure Range: 1 to 10 bar Medium: Filtered compressed air, lubricated or non-lubricated Piston Rod Material: Stainless steel Barrel Material: Anodized aluminum End Cap Material: Pressure die-cast aluminum Ambient Temperature Range: -20°C to +80°C Maximum Speed: Up to 1 m/s Theoretical Force at 6 bar: 1178 N (extend), 981 N (retract) Port Size: G1/4 Position Sensing: Magnetic piston with sensor mounting slots Weight: Approx. 3.5 kg Application: Suitable for clamping, pushing, lifting, and linear automation tasks
Condition: Used
Weight: 15.00
Depth: 20.00
Length: 20.00
Width: 30.00
SKU: 52335 4.S4.15.1
