In stock 1 available
Industrial power contactor from the LC1D series, designed for controlling electric motors and power circuits. Suitable for applications up to 600V with a 24V control coil and robust 32A current handling. Manufacturer: Telemecanique (Schneider Electric) Model: LC1D1800 Coil Voltage: 24 V Main Contact Configuration: 3P (3 NO) Rated Operational Voltage: 600 VAC Rated Current (AC-3): 32 A Power Rating: – 7.5 kW @ 230V (3-phase) – 15 kW @ 400/480V (3-phase) – 20 HP @ 230V (3-phase), 40 HP @ 480V (3-phase) Auxiliary Contacts: 1 NO + 1 NC (A600 / P600 rated) Impulse Withstand Voltage: 8 kV Control Circuit Voltage Range: 20–27 VDC typical Frequency: 50/60 Hz Wire Size: 8–18 AWG Torque: 15 lb-in Mounting: DIN rail or panel mount Standards: IEC 60947, UL 508, CSA, CE Made in: France Application: Motor starters, HVAC systems, pumps, conveyors, automation panels Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 0.10
Depth: 4.00
Length: 7.00
Width: 7.00
SKU: 5240 4.S4.14.3
