Allen-Bradley 2094-BM02-M SER.A Kinetix 6200/6500 Axis Module 400/480V 14.6A

The Allen-Bradley 2094-BM02-M is a Kinetix 6200/6500 axis power module designed for use in high-performance, multi-axis motion control applications. It supports modular integration with servo drives and enables precise motor control in demanding environments. Technical Specifications Manufacturer: Allen-Bradley (Rockwell Automation) Series: Kinetix 6200 / 6500 Catalog Number: 2094-BM02-M Series: A Module Type: Axis Power Module Bulletin: 2094 Bus Input Voltage: 650 VDC Bus Input Current: 10.1 A Control Input Voltage: 95–264 VAC Control Input Current: 0.75 A Control Input Phase: Single Phase Control Input Frequency: 50–60 Hz Motor Output Voltage: 0–480 VAC Motor Output Power: 3-phase, 0–590 Hz Motor Output Current (Continuous): 14.6 A Motor Output Current (Peak): 38.4 A Max Short Circuit Current Rating: 200,000 A Certifications: UL Listed, cUL, CE, TUV Product of: Mexico

Condition: Used

Weight:   10.00

Depth:   16.00

Length:   16.00

Width:   16.00

SKU:   53105 4.R2.2.3
