Wittenstein SC-075S-MF1-2-1E1-1K00 Right Angle Gear Box Ratio 2:1

The Wittenstein SC-075S-MF1-2-1E1-1K00 is a right-angle bevel gearbox designed for high-performance applications requiring a 2:1 reduction ratio. Part of Wittenstein's SC+ series, this gearbox offers a compact design, making it suitable for installations where space is limited. Key Specifications: Gearbox Type: Right-angle bevel gearbox Frame Size: 075 Reduction Ratio: 2:1 Output Shaft: Keyed shaft Backlash: ≤ 4 arcminutes Max. Input Speed: 6,000 RPM Efficiency: Up to 96% at full load Mounting Configuration: Motor-mounted Protection Class: IP65 The SC+ series is engineered for applications that demand high precision and efficiency. Its right-angle design allows for shorter machine configurations, optimizing space without compromising performance. The gearbox is lubricated for life, reducing maintenance requirements and ensuring a long service life exceeding 20,000 hours.

Condition: New

Weight:   12.00

Depth:   10.00

Length:   12.00

Width:   16.00

SKU:   53248 4.R1.5.3, 4.R5.1.4.3
