Product Specifications
| Attribute | Details |
|---|---|
| Model | FMA-63-2.5-1/4-EN |
| Part Number | 159601 |
| Measurement Range | 0 – 2.5 bar (0 – 36 psi) |
| Nominal Size | 63 mm |
| Pneumatic Connection | G 1/4" |
| Mounting Type | Rear panel mounting |
| Connection Position | Rear center |
| Operating Temperature | -20°C to +60°C |
| Accuracy Class | 2.5 (EN 837-1) |
| Gauge Type | Bourdon tube |
| Protection Class | IP43 |
| Material (Housing) | ABS, black |
| Window | SAN (Styrene Acrylonitrile) |
| Media Compatibility | Inert gases and neutral fluids (excluding oxygen and acetylene) |
| Continuous Load Limit | 75% of full scale |
| Intermittent Load Limit | 66% of full scale |
| Weight | Approx. 120 g |
| Materials in Contact with Medium | Brass |
| Standard Compliance | EN 837-1 |
