Sew-Eurodrive SA47 DRE80MA Gearmotor 0.75kW W/Gear Reducer 20.33:1 Ratio

The SEW-Eurodrive SA47 DRE80MA is a helical-worm gearmotor designed for industrial applications requiring high efficiency, compact design, and reliable torque transmission. It integrates a 0.75 kW motor with a 20.33:1 gear reduction ratio, providing smooth, low-noise operation suitable for conveyors, automation systems, and material handling applications. Technical Specifications: Motor Power: 0.75 kW (1 HP) Gear Reduction Ratio: 20.33:1 Output Speed: ~86 RPM (based on a standard motor speed of 1745 RPM) Torque Output: Approx. 152 Nm (varies with load conditions) Shaft Diameter: 25 mm (hollow shaft) Mounting Type: Foot-mounted Motor Efficiency Class: IE3 (Premium Efficiency) Protection Class: IP55 (dust-protected, water-jet resistant) Lubrication: Factory-filled synthetic oil for extended service life

Condition: Used

Weight:   57.00

Depth:   12.00

Length:   14.00

Width:   20.00

SKU:   56372 4.R6.6.5
