Parker PS90-030-010SU Gear head, 30:1 Ratio

The Parker PS90-030-010SU is a precision planetary gearhead engineered for servo and stepper motor applications requiring high torque and compact size. With a 30:1 reduction ratio, it ensures high torque multiplication, excellent torsional rigidity, and low backlash performance, ideal for demanding motion control systems. Technical Specifications: Ratio: 30:1 Frame Size: 90 mm Gear Type: Planetary Mounting Style: Inline Output Shaft Type: Solid, straight shaft Backlash: ≤ 12 arc-min (standard) Torque Capacity (Nominal): ~70 Nm (varies by input speed and duty cycle) Maximum Output Torque: ~130 Nm Efficiency: ≥ 95% Lubrication: Lifetime grease-lubricated Operating Temperature: -25°C to +90°C Housing Material: Aluminum Input Compatibility: Designed for direct coupling with Parker motors; adapter plates available for other motors Weight: ~2.8 kg Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   14.00

Depth:   8.00

Length:   8.00

Width:   8.00

SKU:   57268 4.S5.5.3
