Allen-Bradley 2094-BM02-S SER.C Kinetix 6000 Axis Module

Allen-Bradley 2094-BM02-S Kinetix 6000 Axis Module - Technical Specifications General Information: Model Number: 2094-BM02-S Series: Kinetix 6000 Type: Axis Module Voltage Class: 400/460V AC Inverter Current Rating: 15 A Continuous Power Output: 6.6 kW Safety Feature: Safe Torque-Off (STO) Electrical Specifications: Nominal Input Voltage: 650V DC Continuous Output Current (RMS): 10.3 A Continuous Output Current (Sine 0-Peak): 14.6 A Peak Output Current: 25.8 A Efficiency: Approximately 98% Short-Circuit Current Rating: 200,000 A (RMS) symmetrical Performance Characteristics: Velocity Loop Bandwidth: 500 Hz Current Loop Bandwidth: 1300 Hz Pulse Width Modulation (PWM) Frequency: 4 kHz

Condition: Used

Weight:   15.00

Depth:   6.00

Length:   12.00

Width:   15.00

SKU:   57526 4.R2.1.4
