Mitsubishi Electric A1SX42-S2 Input Unit 24VDC 5mA

Digital input module for Mitsubishi MELSEC System Q and AnS Series PLCs. Designed to receive 24V DC signals with high-speed response, suitable for detecting on/off states of field devices such as sensors and switches. Technical Specifications: Model: A1SX42-S2 Type: Digital input module Number of Input Points: 32 points Input Voltage: 24 VDC ±10% Input Current: 5 mA per point Input Type: Sink type (common negative) Input Response Time: 10 ms max Rated Insulation Voltage: 300 V AC Isolation Method: Photocoupler Common Terminal Configuration: 8 points/common, 4 commons total External Wiring: Screw terminal block Internal Current Consumption: 0.2 A at 5 VDC Mounting: MELSEC AnS Series base unit Operating Temperature: 0°C to 55°C Storage Temperature: -25°C to 75°C Ambient Humidity: 5% to 95% RH (non-condensing) Insulation Resistance: Minimum 5 MΩ (500 VDC) Dielectric Strength: 500 V AC for 1 minute Dimensions: Approx. 130 mm (H) × 35 mm (W) × 90 mm (D) Weight: Approx. 0.25 kg LED Indicators: Yes (input ON indication per channel) Module Classification: I/O module Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.80

Depth:   4.00

Length:   10.00

Width:   8.00

SKU:   658 4.S9.14.4
