In stock 10 available
Pilot-operated directional control valve designed for hydraulic systems requiring flow blocking until pilot pressure is applied. Commonly used in circuits where controlled reverse flow and load holding are necessary. Technical Specifications: Model Code: DGMPC-3-BAN-41J Manufacturer: Tokimec Inc. / Vickers (Trinova Ltd.) Valve Type: Pilot Operated Check Valve Function: P→A, B→T with pilot release from A and B ports respectively Mounting: Subplate mounting (modular stack type) Port Configuration: P, T, A, B (standard four-port layout) Max Operating Pressure: 315 bar (4568 psi) Size: NG6 (Cetop 3 / ISO 4401-03) Fluid Type: Hydraulic oil (mineral-based) Pilot Ratio: Typically 3:1 (depending on model variation) Body Material: Cast iron Seal Material: Nitrile (standard) Interface: CETOP 03 / NFPA D03 pattern Operating Temperature: -20°C to +70°C Weight: Approx. 2.3 kg Please review pictures carefully and let us know if you have any questions!
Condition: Used
Weight: 2.20
Depth: 4.00
Length: 7.00
Width: 7.00
SKU: 686 4.S9.10.4
