Vickers DGMEN3XA2H41J Tokimec Check Valve

Electrically operated proportional directional control valve used in hydraulic systems to regulate flow and direction continuously in response to an analog input signal. Ideal for precise control of actuator speed and position in industrial automation. Technical Specifications: Model Code: DGMEN-3-XA-2H-41-J Valve Type: Proportional directional control valve Operation: Solenoid-actuated, direct-operated Mounting Pattern: NG6 / CETOP 3 / ISO 4401-03 Spool Type: Type XA (for bidirectional metering with A-B crossover) Control Signal: ±10 V analog input (standard) Power Supply: 24 VDC for solenoids Max Operating Pressure: 315 bar (4568 psi) Rated Flow: Typically up to 25 L/min (dependent on spool type and pressure drop) Electrical Connection: 6-pin DIN connector (per EN 175301-803) Coil Resistance: Nominal 6.6 Ω at 20°C Hysteresis: <5% of rated input Repeatability: Better than 1% Hydraulic Fluid: Mineral oil (ISO VG 32 recommended) Fluid Temperature Range: -20°C to +70°C Ambient Temperature Range: -20°C to +60°C Filtration: ISO 4406 18/14 or better Material: Cast iron body, precision-machined spool Weight: Approx. 2.4 kg Manufacturer: Tokimec Inc. / Vickers (Trinova Ltd.) Country of Origin: England Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   2.40

Depth:   4.00

Length:   7.00

Width:   4.00

SKU:   688 4.S10.1.3I
