Mitsubishi CP30-BA Circuit Protector 10Amp

Compact miniature circuit breaker designed to protect electrical equipment from overload and short-circuit faults in control panels and industrial systems. Ideal for DIN rail mounting in space-constrained applications. Technical Specifications: Model: CP30-BA Poles: 2-pole Rated Current: 10 A Rated Voltage: AC 220 V Interrupting Capacity (I.C.): 2.5 kA Ui (Rated Insulation Voltage): 250 VAC / 125 VDC Operating Temperature: 40°C (ambient) Trip Curve: Curve M (medium delay for moderate inrush currents) Standard Compliance: IEC 934 Breaking Capacity: – 230 VAC: 2.5 kA – 120 VDC: 2.5 kA – 125 VDC: 2.5 kA – 240 VAC: 2.5 kA Mounting: DIN rail Terminal Type: Screw terminals Manufacturer: Mitsubishi Electric / Kyowa Made in: Japan Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   0.20

Depth:   16.00

Length:   12.00

Width:   10.00

SKU:   693 4.S9.7.2
