Mitsubishi NF100-CP-3P-100A Circuit Breaker 600VAC 100Amp

Three-pole no-fuse molded case circuit breaker (MCCB) designed for overload and short-circuit protection in low-voltage distribution systems. Compact and reliable for industrial power panel installations. Technical Specifications: Model: NF100-CP Type: MCCB (No-Fuse Breaker) Poles: 3P (3-pole) Rated Current: 100 A Rated Voltage (Ui): 600 VAC Rated Operational Voltage (Ue): – JIS: 550 VAC / 460 VAC / 220 VAC – IEC 947-2 / EN60947-2: 500 VAC / 400 VAC / 230 VAC Breaking Capacity (Icu/Ics): – 550 VAC: 7.5 kA – 460 VAC: 10 kA – 220 VAC: 25 kA – 500 VAC: 7.5 kA / 4.5 kA – 400 VAC: 10 kA / 5 kA – 230 VAC: 25 kA / 13 kA Frequency: 50/60 Hz Interrupting Capacity (I.C.): 25 kA at 220 VAC Trip Mechanism: Thermal-magnetic Operation: Toggle switch with push-to-trip button Mounting: Panel mount Terminal Type: Screw terminals Ambient Temperature: 40°C standard Compliance: IEC 60947-2, JIS C8201 Manufacturer: Mitsubishi Electric Made in: Japan Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   2.00

Depth:   16.00

Length:   12.00

Width:   10.00

SKU:   700 4.S9.11.4
