Trimble 33429-00 GPS Antenna W/Bag

The Trimble 33429-00 is a high-performance GPS L1 antenna designed for use in precise timing and positioning applications. It is optimized for use with Trimble receivers and is commonly deployed in infrastructure, survey, and embedded timing systems. Technical Information: Manufacturer: Trimble Part Number: 33429-00 Type: GPS L1 active antenna Frequency: L1 band (1575.42 MHz) Gain: Typically +26 dB (active gain with LNA) Voltage Input: 2.7V to 5.5V DC (supplied through coaxial cable) Current Consumption: ~20–25 mA Connector Type: TNC female (common), SMA variants may exist Mounting: Magnetic base or pole mount (depending on configuration) Cable Length: Typically 5m or longer (customizable) Impedance: 50 ohms Operating Temperature: -40°C to +85°C Weatherproofing: IP67 rated housing (sealed for outdoor use) Applications: GNSS-based timing systems, fixed-position receivers, network synchronization, industrial automation, and outdoor telecom enclosures Please review pictures carefully and let us know if you have any questions!

Condition: Used

Weight:   10.10

Depth:   16.00

Length:   26.00

Width:   18.00

SKU:   7068 4.S9.13.6
