Ball Valves
In stock 1 available
Anchor Fluid Power AE2N1/4-11DB 1/4" Ball Valve
Compact, manually operated ball valve ideal for hydraulic and pneumatic systems where reliable shutoff and compact size are needed.
Body Style: Two-piece
Valve Type: Ball Valve
Connection Type: NPT Female
Port Size: 1/4"
Orifice Size: 0.20"
Material (Body): Zinc-plated carbon steel
Ball Material: Chrome-plated steel
Seal Material: Buna-N
Handle: Lever type
Max Operating Pressure: 5000 PSI
Temperature Range: -40°F to 250°F (-40°C to 121°C)
Thread Standard: ANSI B1.20.1 NPT
Mounting: Panel mount capable
Part Number: AE2N1/4-11DB
Manufacturer: Anchor Fluid Power Please review pictures carefully and let us know if you have any questions!
